FC APC Fiber Connector Simplex 3.0mm Boot

Name: FC APC Fiber Connector Simplex 30mm Boot
Brand: GoreLink
Price: 1 USD

Wholesale FC APC Fiber Connector Simplex 3.0mm Boot from china suppliers

Brand Name : GoreLink

Model Number : G519-831

Certification : CE,RoHS

Place of Origin : China

MOQ : 1pc

Payment Terms : T/T, Western Union,Paypal

Delivery Time : 1-3 Working days

Packaging Details : 200pcs/Pkt

Product name : FC/APC Fiber Optic Connector

Application : FTTH FTTB FTTX Network,Telecommunication

Part No. : G519-831

Fiber Type : FC/APC

Fiber Mode : Singlemode

Structure : Simplex

Color : Green

Fiber cable type : 2.0mm 3.0mm cable

Insert loss : ≤0.3dB

Return loss : ≥50dB

Compliance : RoHS compliant

Operating temperature : -40°C ~ +80°C

Contact Now

FC/APC Singlemode Simplex 3.0mm Fiber Optic Connector

Gorelink manufacture various kinds of Single Mode and Multimode fiber optic connectors for fiber connecting applications. Each fiber optic connector is functionally tested before shipping and is covered by a lifetime warranty.

Application

FTTH access network
Telecommunication Networks
CCTV Networks
Data Center
Local Area Networks

General Specification

Fiber Connector Type	FC/APC
Body Style	Simplex
Fiber Mode	Singlemode
Hoursing/Boot Color	Metal-Black
Compatible cable diameter	3.0mm
Flammability Rate	UL94-V0
Compliant	RoHS, Telcordia GR-326-CORE

Optical Specification

Parameter	Singlemode			Multimode
Parameter	PC	UPC	APC	UPC
Insertion loss	≤0.3dB	≤0.3dB	≤0.3dB	≤0.25dB
Return loss	≥55dB	≥55dB	≥60dB	/
Wavelength	1310nm, 1550nm			850nm, 1300nm
Ferrule Concentricity	≤1um			≤4um
Operating Temperature	-20°C to +70°C
Storage Temperature	-40°C to +85°C

FC APC Fiber Connector Simplex 3.0mm Boot

Download Datasheet

Fiber Optic Connectors-FC Series

Ordering Information

PART NO.	DESCRIPTION
G519-831	FC/APC Singlemode Simplex 3.0mm Fiber Optic Connector

If you need any further assistance, please feel free to contact us at sales@gorelink.com .
