UTP 24AWG Stranded Cat6 Patch Cord PVC 1m Copper Patch Cord Blue

Brand Name : GoreLink

Model Number : GC-U624-BL-1

Certification : CE,RoHS

Place of Origin : China

MOQ : Negotiable

Payment Terms : T/T, Western Union,Paypal

Delivery Time : 10-15 Working days

Packaging Details : 1pcs/bag

Product name : Copper Patch Cord

Application : 1000 Base-T Gigabit Ethernet

Category Rating : Category 6

Shield : UTP

Wire Gauge : 24AWG

Conductor Material : Stranded copper

Length : 1m / Customized

Jacket : PVC

Color : Blue

Frequency : 250MHz

Operating temperature : 0-60°C

Contact Now


Patch Cable, Cat6, 4 Pair,Stranded Copper, UTP, PVC, Blue, 1Mtr

Gorelink Category 6 (Unshielded U/UTP) is designed to Gigabit Ethernet applications is ideal for voice, data, video and security communication mediums for all your network- installation requirements. This Cat6 patch leads consist of 4 twisted pairs of 24 AWG stranded copper wires. These pairs are then cabled together, with different lay lengths to ensure optimum performance. Staggered pin RJ45 plugs terminate the cable, and each lead is fitted with colour coded moulded boots, suitable for use in high density router or switch blades.



Application

  • ATM

  • Gigabit Ethernet

  • Data center

  • PoE Applications

  • Rated for any 1000 Base-T Ethernet.

  • Perfect for data center and SMB applications.

  • Ideal for switches, servers, patch panels, or other equipment.



General Specification

Category

Cat6

Cable Type

UTP

Conductor

Stranded Copper

Conductor Gauge(AWG)

24AWG

Termination

RJ45

Jacket

PVC (LSZH available)

Color

Blue

Length

1m

Operation temperature

0 to 70°C

Storage Temperature

-40 to 85°C

Relative Humidity

5% to 95%

Technical Characteristics

Data Rate Support

1000Base-T

Standard Bandwidth (MHz)

250MHz

Impedance (Ω)

100 ± 15

Max. DC Conductor Resistance Unbalance (%)

5.0

1-250MHz, Delay Skew 20℃ (ns/100m)

≤45

Max. DC Resistance 20℃ (Ω/100m)

9.38

Before Aging Tensile Strength (Mpa)

≥13.5

After Aging Tensile Strength (Mpa)

≥12.5



UTP 24AWG Stranded Cat6 Patch Cord PVC 1m Copper Patch Cord Blue


Download Datasheet

UTP Cat6 Patch Cables


Ordering Information

PART NO.

DESCRIPTION

GC-U624-BL-1

Gorelink UTP CAT6 PATCH CORD, 24AWG, COPPER, PVC JACKET, Blue, 1m

GC-U624-BL-2

Gorelink UTP CAT6 PATCH CORD, 24AWG, COPPER, PVC JACKET, Blue, 2m

GC-U624-BL-3

Gorelink UTP CAT6 PATCH CORD, 24AWG, COPPER, PVC JACKET, Blue, 3m

GC-U624-BL-5

Gorelink UTP CAT6 PATCH CORD, 24AWG, COPPER, PVC JACKET, Blue, 5m

GC-U624-BL-10

Gorelink UTP CAT6 PATCH CORD, 24AWG, COPPER, PVC JACKET, Blue, 10m

GC-U624-BL-15

Gorelink UTP CAT6 PATCH CORD, 24AWG, COPPER, PVC JACKET, Blue, 15m

GC-U624-BL-20

Gorelink UTP CAT6 PATCH CORD, 24AWG, COPPER, PVC JACKET, Blue, 20m

* Customized
